4-OPERATINGINSTRUCTIONS
6.Usetheproportionalswitchtooperatetheconcrete
crusher.
NOTICE:InBucketmode,donotcarryoutoperationus-
ingauxiliaryline.Ifyoudothatthewarningmessage
“Auxiliaryset-uprequired”willbedisplayedwithintermit-
tentwhistlesound.Stopoperationimmediatelyandcarry
outauxiliaryset-up.
NOTE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateandpressureforthetool.
EC3339BB29
Auxiliaryhydrauliccircuitowpatterns
Flowpatternscanbeselectedfromthe20shownbelow.
NOTE:Thenumberofsettingpatternsis10maximum.
1ow2ows
210l/min(55.5USgpm)420l/min(111.0USgpm)
196l/min(51.8USgpm)406l/min(107.3USgpm)
182l/min(48.1USgpm)392l/min(103.6USgpm)
166l/min(43.9USgpm)376l/min(99.3USgpm)
146l/min(38.6USgpm)356l/min(94.0USgpm)
129l/min(34.1USgpm)339l/min(89.6USgpm)
111l/min(29.3USgpm)321l/min(84.8USgpm)
94l/min(24.8USgpm)304l/min(80.3USgpm)
74l/min(19.5USgpm)284l/min(75.0USgpm)
50l/min(13.2USgpm)260l/min(68.7USgpm)
Optionpressuresetting
Anoptionpressurefrom19-34.5MPa(2756.0-5004.2
psi)canbeselectedin0.5MPa(72.5psi)increments.
4-41
