Draining
CAUTION
Burnhazard!
Hotcoolantcansprayoutifyouremovethe
llercapwhilethesystemishot.Afterthe
systemhascooled,turnthellercaptothe
rstnotchandwaitforallpressuretorelease
beforeproceeding.
Failuretocomplycouldresultinminoror
moderateinjury.
C0043A
1.Removetheradiatorplug.
2.Removethreeboltsontheprotectivepanelintherear
left-handcompartmentundertheradiatorandremove
thepaneltoaccesstheradiatordrainvalve.
K272V1-0022
3.Opentheradiatordrainvalvelocatedintherearleft-
handcompartment.
K272V1-0033
4.Openthedrainpluglocatedontheengineblock.
NOTE:Haveareceptacleofasuitablecapacityready.
K272V1-0084
