Case CX235C SR - Page 214

6-MAINTENANCE
2.Closethevalve(1)onthefueltanklineandclosethe
valve(2)ontheengineline.
BF67A47F8
3.Cleanaroundthefuellterbody.
NOTICE:Neverusethecleanerbecausethatcan
causedamage.
4.Loosenthedrainplug(3)andthebleedscrew(4).
F3E62F909
5.Cleanaroundthefuellterbodythenremoveitusing
thewrenchprovidedwiththemachine.
6.Installthenewfuellterelement.Replacethefuellter
bodyseal,theninstallthebody,turningituntilitisin
contactwiththefuellterhead.
ATTENTION:Donotllthelterbodywithfuelbefore
installing.
7.Tightenthebodyusingthewrench,thetightening
torquemustbefrom28-32N·m(20.7-23.6lbft).
NOTE:Bindtightwithinregulationtorque.
QOIPZB-01010
8.Replacethedrainplug(3)sealtheninstallthedrain
plug(3);thetighteningtorquemustbebetween8-12
N·m(5.9-8.9lbft)
ATTENTION:Overtighteningcandamagetheseal.
ATTENTION:Neverre-usethesealofthelterbody
orthedrainplug(3);theymustalwaysbereplaced
withnewseal.
NOTE:Bindtightwithinregulationtorque.
F3E62F90A11
6-30
