6-MAINTENANCE
Toreducetension
WARNING
Pressurizeduidcanpenetratetheskinand
causesevereinjuries.
Thegreaseinthecylinderisunderhighpres-
sure.Neverloosenthegreasettingadaptor
completelyinordertospeeduptheowof
grease.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0261A
1.Loosenthegreasettingadaptorbyaboutthreeturns
toallowgreasetoowoutofthecylinder.
2.Assoonastherighttracktensionisobtained,tighten
theadaptor.
Thevaluemustbebetween:280mm(11.0in)and
300mm(11.8in).
3.Cleanthegreaseadaptorandttingandthenlower
theraisedtracktotheground.
4.RepeatSteps1to3fortheothertrack.
NOTICE:Ifthegreasettingadaptorisdamaged,grease
mayleakout.Checktheconditionofthegreasetting
adaptorregularlyandreplaceitifnecessary.
WRQF7U-0017
Tighteningtorqueofthetrackpadscrews
ATTENTION:Regularlycheckthetighteningofthe
screws.Donotusethemachinewiththetrackpad
screwsloose,thescrewsmaycomeoffanddamagethe
track.
Thetighteningtorqueofthescrewsmustbe:
600mm(23.6in)steeltrack:250-350N·m(184-258.1
lbft)
800mm(31.5in)steeltrack:755-853N·m(556.9-629.1
lbft)
UEBLNV-0018
NOTE:Followtheprescribedorder.
UEBLNV-0029
