6-MAINTENANCE

Cleaningthecirculationlter

WARNING

Flyingdebris!

Compressedaircanpropeldirt,rust,etc.into

theair.Weareyeandfaceprotectionwhen

usingcompressedair.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0307A

1.Removethelterandcleanitwithcompressedair.If

thelterisdamaged,replaceit.

2.Installthelter.

1AF577062

Cleaningthesuctionlter

WARNING

Flyingdebris!

Compressedaircanpropeldirt,rust,etc.into

theair.Weareyeandfaceprotectionwhen

usingcompressedair.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0307A

1.Removetheaircirculationlterlocatedonthebottom

ofthebackoftheoperator'sseatandcleanitwith

compressedair.Ifthelterisdamaged,replaceit.

7252954E3

2.Followtheinstallationprocedureandplacethelterin

thehousing.

E67DC94E4

6-71
