Case CX235C SR - Quick Coupler (Optional) Dimensions

8-SPECIFICATIONS
Arms
2.40m(94.49in)2.94m(115.75in)
(A)(Maximumdiggingreach)9.37m(368.90in)9.85m(387.80in)
(B)(Maximumdiggingreachatgroundlevel)9.18m(361.42in)9.67m(380.71in)
(C)(Maximumdiggingdepth)6.12m(240.94in)6.65m(261.81in)
(D)(Maximumdiggingdepthoveralengthof
2.44m(96.06in))
5.91m(232.68in)6.48m(255.12in)
(E)(Maximumdumpheight)7.63m(300.39in)7.97m(313.78in)
(F)(Maximumworkingheight)10.52m(414.17in)10.86m(427.56in)
(G)(Minimumattachmentswingradius)2.55m(100.39in)2.31m(90.94in)
(H)(Maximumdiggingdepthonavertical
face)
5.48m(215.75in)5.92m(233.07in)
(I)(Maximumlengthofat-bottomedtrench)2.44m(96.06in)2.44m(96.06in)
Quickcoupler(Optional)
Dimensionsneededtotthequickcoupler
Bucketpindiameter80mm(3.1in)
Widthbetweenlugs
307mm(12.1in)
Minimumdistancebetweenbucketcentres
435mm(17.1in)
Maximumdistancebetweenbucketcentres
512mm(20.2in)
ATTENTION:ThequickcouplerdescribedinthismanualisdesignedtobeusedwithCASEbuckets.Thisbeingsaid,
otherbucketsmaybeused,providedthediameterofthepinsandthewidthbetweenthebucketlugsaremodied
tomeetthedimensionsneededtotthequickcoupler(pins,washers,bushings,etc.).ConsultyourCASECON-
STRUCTIONDealer.
Weight
440kg(970.0lb)
Overalldimensions
W4HFRI-0034
(A)990mm(39.0in)
(B)580mm(22.8in)
(C)470mm(18.5in)
8-9
