2-SAFETYINFORMATION
Controlpatternselector(ifequipped)
Partnumber:KHP1757
Thisdecalshowsthepositioninwhichtheselectormust
beplacedaccordingtotheselectedcongurationtypeof
thecontrollevers.See“Controlpatternselection”decal.
KHP1757-00B21
Windshieldlocking
Partnumber:KHP12540
Thisdecalshowsthatthewindshieldmustbecorrectly
lockedinopenposition,inordertopreventitfromtipping.
QA96IC-00122
Functionoftheleversandpedals
Partnumber:
KHP1498(standard)
KHP1484(withright-handoption)
KHP1510(withleft-handoption)
KHP1511(withrightandleft-handoptions)
KHP1572(withdozerbladeifequipped)
KHP1573(withoptionanddozerbladeifequipped)
Thisdecalshowsthefunctionofthetravelcontrollevers
andpedals.
KHP148623
Cigarettelightersocket(24volts)
Partnumber:KHP11590
Thisdecalshowsthelocationandthevoltageofthe
cigarettelightersocket.Itisstrictlyprohibitedtoconnect
devicesofadifferentvoltage.
DEXSB6-00124
