3-CONTROLS/INSTRUMENTS

Adjustmentandlockingtheauxiliarypedals

(ifequipped)

WARNING

Unexpectedmachinemovement!

Shutdowntheenginebeforeadjustingthe

auxiliarypedals.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0277A

Theadjustmentofauxiliarypedalsisadaptedforusewith

theaccessoryinstalledontheattachment.

Accessoryusingtwopedalowscanbeoperatedintwo

directions,thelockingpin(1)isremoved.

SNKQ6K-00117

Accessoryusingasingleowcanbeoperatedinonlyone

direction,thelockingpin(1)isengaged.

SNKQ6K-00218

Accessoryremoved,thepedalsmustbelocked,thelock-

ingpin(1)isengagedinthelockinghole.

SNKQ6K-00319

3-14
