E
30
Margins
You can select from among the following four margin settings.
Note
• All of the margin measurements mentioned below are approximate.
NARROW
MEDIUM
WIDE
Important!
• Margins are not cut in the case of short tape lengths (28mm (1 1/8")
for NARROW, 35mm (1 3/8") for MEDIUM, 44mm (1 3/4") for WIDE).
After printing, you can use scissors to trim to the margin you want.
NONE
• Setting with the NONE setting makes it possible to print consecutive
labels one after another.
• The auto tape cut operation is not performed when NONE is selected
for the margins. To cut the tape, press CUT.
3.0mm (1/8")
10mm (3/8")
19mm (3/4")
19mm (3/4")
3.0mm (1/8")
10mm (3/8")
FREE DESIGN: Controlling the Length of a Tape
Label
Tape label length is normally adjusted in accordance with the size and number
of the characters in the label. This section explains how you can control the
length of your labels.
1. In the Free Design Mode, input the text you want.
2. Press FORM.
3. Use and to scroll to the TAPE LENGTH setting screen.
4. Use and to change the setting to FIX, and then press .
5. Use the number keys, or the (decrease) and (increase) keys to
change the label length setting.
• The appearance of the tape length value on the display will change in
accordance with your setting as described below.
6. Press SET.
[20.6cm]
Label can be printed
as specified.
➜
Length value becomes highlighted.
20.5cm]
Label will be printed but
the tape length will be
longer than specified.
➜
(20.6cm]
Label will be printed at
specified length with
condensed characters.
➜
To Next Page
