Casio KL-7400 User Manual

E
48
Battery Life
• Printing of approximately two 18mm tape cartridges under standard
printing conditions*
* Printing text or graphics that contain large areas of black, and printing
under cold temperatures can shorten battery life.
• Be sure to replace batteries at least once every two years, even if you
do not use the printer during that period.
■ Changing the AC Plug
Perform the following steps when you need to change the AC plug that is
installed on the AC adaptor.
1. Slide the plug in the direction of the ar-
row in Figure 1, and remove it from the
AC adaptor.
Figure 1
2. Align the plug that matches the power
outlet of your area with the AC adaptor
slots. Slide it in place in the direction of
the arrow shown in Figure 2.
Figure 2
3. Press the part indicated by the arrow in
Figure 3 until the plug clicks securely into
place.
Figure 3

Casio KL-7400 Specifications

General

Color	Yes
Printing colors	Black
Print technology	Direct thermal
Vertical printing	No
Maximum resolution	200 x 200 DPI
Maximum print height	24 mm
Maximum print size	-
Product color	Silver
Keyboard layout	QWERTY
Connectivity technology	Wired
Dimensions (WxDxH)	202 x 216 x 64.5 mm
Print sizes included	1x1 - 4x4
Battery type	AA
Battery technology	Alkaline
Power requirements	AC
Number of batteries supported	8
Tape cutting	Automatic
Number of printing lines (max)	3

Weight and Dimensions

Depth	216 mm
Width	202 mm
Height	64.5 mm
Weight	750 g
