7.11 Sostenuto (42H)
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 : For information about the relationship between setting values and send/receive values, see the “39.1 Off/On Setting
Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Send Sent when a pedal that has a sostenuto function is operated.
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
7.12 Soft (43H)
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 : For information about the relationship between setting values and send/receive values, see the “39.1 Off/On Setting
Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Send Sent when a pedal that has a soft function is operated.
Receive Receipt performs an operation equivalent to a soft pedal operation.
7.13 Drawbar Position 16’(46H)(Drawbar tone selected)
Note : This message is valid only when a drawbar tone is selected for the MIDI channel.
Message Format: BnH 46H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 : For information about the relationship between setting values and send/receive values, see the “39.5 Drawbar
Position Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Send Sent when a drawbar 16’ is operated.
Receive Receipt changes the drawbar 16’ position.
7.14 Filter Resonance(47H)
Message Format: BnH 47H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the resonance intensity.
16

Casio XW-P1 Specifications

General

Polyphony	64 notes
Arpeggiator	Yes, 6 types
Power Supply	D batteries x 6, AC Adapter
Dimensions	95.7 x 39.7 x 11.1 cm
Weight	13.2 lbs
Effects	Reverb, Chorus, Delay, Distortion, Rotary Speaker
Display	LCD
User Tones	100
Inputs/Outputs	USB
User memory	100 user tones
Controllers	Pitch Bend Wheel, Modulation Wheel
Inputs	Line In
Outputs	1/4" L/Mono, R output
Keyboard	61 keys
Connections	USB
