24.2 Velocity Split Parameter (x4velocity-split x128instrument)
These parameters are for configuring velocity split for each drum tone instrument.
Parameter ID R/W Block Size Array Min-Def-Max Description
Range Top 0007 R/W 13-7:Inst 7 01 00-7F-7F Velocity upper limit value
2-0:Split
Number 0008 R/W ↑ 14 01 0000-0000-3FFF Inst number
0-376
24.3 LFO Parameter
These parameters configure drum tone LFO settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Pitch LFO Wave Type 0009 R/W 00000000 4 01 00-00-0F 0...Sin
1...Tri
2...Saw Up
3...Saw Down
4...Pulse 1:3
5...Pulse 2:2
6...Pulse 3:1
Pitch LFO Rate 000A R/W ↑ 7 01 00-40-7F 0 - 127
Pitch Auto Delay 000B R/W ↑ 7 01 00-00-7F 0 - 127
Pitch Auto Rise 000C R/W ↑ 7 01 00-00-7F 0 - 127
Pitch Auto Depth 000D R/W ↑ 8 01 00-80-FF -128 - 0 - +127
Pitch Mod Depth 000E R/W ↑ 7 01 00-40-7F 0 - 127
(effective:-64 - 0 - +63)
Pitch After Depth 000F R/W ↑ 7 01 00-40-7F 0 - 127
(effective:-64 - 0 - +63)
Amp LFO Wave Type 0010 R/W ↑ 4 01 00-00-0F 0...Sin
1...Tri
2...Saw Up
3...Saw Down
4...Pulse 1:3
5...Pulse 2:2
6...Pulse 3:1
Amp LFO Rate 0011 R/W ↑ 7 01 00-40-7F 0 - 127
Amp LFO Auto Delay 0012 R/W ↑ 7 01 00-00-7F 0 - 127
Amp LFO Auto Rise 0013 R/W ↑ 7 01 00-00-7F 0 - 127
Amp LFO Auto Depth 0014 R/W ↑ 8 01 00-80-FF -128 - 0 - +127
Amp LFO Mod Depth 0015 R/W ↑ 7 01 00-40-7F 0 - 127
(effective:-64 - 0 - +63)
Amp LFO After Depth 0016 R/W ↑ 7 01 00-40-7F 0 - 127
(effective:-64 - 0 - +63)
25 Drawbar Parameter(XW-P1 only)
25.1 Drawbar Parameter
These parameters configure drawbar tone settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Position 0000 R/W 3-0:Select Bar 4 01 00-00-08 0-8
Percussion 0001 R/W 00000000 2 01 00-00-03 0...off
1...2nd
2...3rd
3...2nd+3rd
Percussion Decay Time 0002 R/W ↑ 7 01 00-00-7F 0 - 127
Keyon Click 0003 R/W ↑ 1 01 00-00-01 0...off
