20.2 System Exclusive Protocol Parameter
These parameters are related to the System Exclusive message protocol.
Parameter ID R/W Block Size Array Min-Def-Max Description
Oneway Min Interval 000E R 00000000 14 01 0000-0014-3FFF Minimum time interval time value
(msec) between packets during
One-way Bulk Dump receive by
Instrument
Oneway Max Interval 000F R/W ↑ 14 01 0000-0800-3FFF Maximum allowable message wait time
(msec) during One-way Bulk Dump
receive by Instrument
Oneway Current Interval 0010 R/W ↑ 14 01 0000-0014-3FFF Current time interval value between
packets during One-way Bulk Dump
send by Instrument
Oneway Max Data Length 0011 R ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes)
of transfer data included in one
packet during One-way Bulk Dump
send/receive by Instrument
Oneway Curent Data Length 0012 R/W ↑ 14 01 0000-0080-3FFF Current memory size value (bytes)
of transfer data included in one
packet during One-way Bulk Dump
send by Instrument
Handshake Max Interval 0013 R/W ↑ 14 01 0000-0800-3FFF Maximum allowable message wait time
(msec) during Handshake Bulk Dump
receive by Instrument
Handshake Max Data Length 0014 R ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes)
of transfer data included in one
packet during Handshake Bulk Dump
send/receive by Instrument
Handshake Currnet Data Length 0015 R/W ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes)
of transfer data included in one
packet during Handshake Bulk Dump
send by Instrument
Handshake Retry Number 0016 R/W ↑ 7 01 00-03-7F Number of retries after error
generation during Handshake Bulk
Dump send
20.3 Data Management Parameter
These are information acquisition and operation command parameters for this Instrument’s Data Man-
ager PC application.
Parameter ID R/W Block Size Array Min-Def-Max Description
Ps Category 0019 W 00000000 7 01 00-00-7F Specifiesthe category ID of the
parameter set that corresponds
to an operation.
Ps Memory 001A W ↑ 7 01 00-00-7F Specifies the memory ID of the
parameter set that corresponds
to an operation.
Ps Number 001B W ↑ 14 01 0000-0001-3FFF Specifies the number of the
parameter set that corresponds
to an operation.
Ps Data Type 001C R ↑ 8 01 00-00-FF The data type of the parameter
set in the specified category.
Compatibility is providedbetween
models with the same type.
Current Ps Existence 001D R ↑ 1 01 00-00-01 Whether a parameter set exists
in the specified category.
0...No
1...Yes
Current Ps Protect 001E R ↑ 1 01 00-00-01 Protect status of a parameter
set data in the specified
category.
0...Off
1...On
Current Ps Size 001F R ↑ 32 01 00000000-00000000-FFFFFFFF Size of a parameter set in the
specified category/number
(bytes).
