Parameter ID R/W Block Size Array Min-Def-Max Description
1...on
Keyoff Click 0004 R/W ↑ 1 01 00-00-01 0...off
1...on
Type 0005 R/W ↑ 1 01 00-00-01 0...Normal
1...Vintage
Vibrato Rate 0006 R/W ↑ 7 01 00-00-7F 0 - 127
Vibrato Depth 0007 R/W ↑ 7 01 00-00-7F 0 - 127
26 Hex Layer Parameter(XW-P1 only)
These parameters configure hex layer tone settings.
26.1 Hex Layer Parameter (x6layer)
These parameters configure basic hex layer tone settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Onoff 0000 R/W 2-0:Layer Number 1 01 00-01-01 0...off
1...on
Split Ui Number 0002 R/W ↑ 16 01 0000-0000-FFFF PCM Wave number
0326-1114
Pan Offset 0003 R/W ↑ 7 01 00-40-7F -64 - 0 - +63
Pitch Key 0004 R/W ↑ 7 01 00-40-7F Added to key number as 0x40
center
Pitch Cent 0005 R/W ↑ 16 01 0000-0000-FFFF S------.- -------- S:sign bit
-------.c cccccccc c:cent
= 100/512 cent resolution
0000001.0 00000000...For +100
cent(1 semitone)
1111111.0 00000000...For -100
cent(1 semitone)
Amp Attack Rate Offset 0006 R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Amp Decay Rate Offset 0007 R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Amp Sustain Level Offset 0008 R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Amp Release Rate Offset 0009 R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Volume Offset 000A R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Cutoff Offset 000B R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Touch Sense Offset 000C R/W ↑ 8 01 00-BF-FF -128 - 0 - 127
Reverb Send Offset 000D R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Chorus Send Offset 000E R/W ↑ 8 01 00-80-FF -128 - 0 - 127
Key Range Low 000F R/W ↑ 7 01 00-00-7F 0 - 127
Key Range High 0010 R/W ↑ 7 01 00-7F-7F 0 - 127
Velocity Range Low 0011 R/W ↑ 7 01 00-00-7F 0 - 127
Lower Limit of Velocity
Velocity Range High 0012 R/W ↑ 7 01 00-7F-7F 0 - 127
Upper Limit of Velocity
Detune Number 0013 R/W 00000000 5 01 00-00-1F 0 - 31
Pitch Lock 0014 R/W 00000000 1 03 00-00-01 0...Unlocked
1...Locked
26.2 Hex Layer LFO Parameter
These parameters configure hex layer tone LFO settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Pitch LFO Wave Type 0015 R/W 00000000 4 01 00-00-0F 0...Sin
1...Tri
2...Saw Up
3...Saw Down
4...Pulse 1:3
