Send Sent when the Master Pan is changed.
Receive Receipt changes the Master Pan.
15.1.3 Master Fine Tuning
Message Format: F0H 7FH ddH 04H 03H llH mmH F7H
dd: Device ID
ll: LSB Value(Note1)
mm: MSB Value(Note1)
Note1 : For information about the relationship between setting values and send/receive values, see “39.4 Fine Tuning Setting
Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Send This message is sent when the tuning setting is changed.
Receive Receipt changes the tuning setting.
15.1.4 Master Coarse Tuning
Message Format: F0H 7FH ddH 04H 04H llH mmH F7H
dd: Device ID
ll: LSB Value(Send:00H、Receive:Ignored)
mm: MSB Value(28H - 58H)
Send This message is sent when the Master Coarse Tune setting is changed.
Receive Receipt changes the Patch Master Coarse Tune parameter.
15.1.5 Reverb Time
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 01H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Reverb duration.
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Chorus Rate.
15.1.6 Send To Reverb
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 04H vvH F7H
dd: Device ID
vv: Value
41

Casio XW-P1 Specifications

General

Polyphony	64 notes
Arpeggiator	Yes, 6 types
Power Supply	D batteries x 6, AC Adapter
Dimensions	95.7 x 39.7 x 11.1 cm
Weight	13.2 lbs
Effects	Reverb, Chorus, Delay, Distortion, Rotary Speaker
Display	LCD
User Tones	100
Inputs/Outputs	USB
User memory	100 user tones
Controllers	Pitch Bend Wheel, Modulation Wheel
Inputs	Line In
Outputs	1/4" L/Mono, R output
Keyboard	61 keys
Connections	USB
