Note : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “20.2 System
Exclusive Protocol Parameter”.
18.3.12 Example: Session Termination by Error Generation
Data Receiver Data Sender Operation
SBS(HBR) -----> Session Start Request
<----- ACK Acknowledge
HBR -----> Send Request
(Optional)
<----- HBS Send Packet
ACK -----> Acknowledge
<-???- HBS Send Packet
<-???- HBS Send Packet
ERR(CRC Error) -----> Error
<-???- HBS Resend Packet
ERR(Format Error) -----> 2 consecutive errors
<-???- HBS Resend Packet
ERR(Time Out Error) -----> 3 consecutive errors
:
<-???- HBS Resend Packet
ERR(CRC Error) -----> N consecutive
errors(*Note)
<-???- HBS Resend Packet
RJC -----> Abandon Session
Note : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “20.2 System
Exclusive Protocol Parameter”. Also, the maximum number of retries is the same, even if multiple instances of the same error are
generated or if multiple different errors are generated.
18.3.13 Example: Intentional Session Termination by an External Device
Data Receiver Data Sender Operation
(External Device) (This Instrument)
SBS(HBR) -----> Session Start Request
<----- ACK Acknowledge
HBR -----> Send Request
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
RJC -----> Terminate Session
18.3.14 Example: Intentional Session Termination by This Instrument
60

Casio XW-P1 Specifications

General

Polyphony	64 notes
Arpeggiator	Yes, 6 types
Power Supply	D batteries x 6, AC Adapter
Dimensions	95.7 x 39.7 x 11.1 cm
Weight	13.2 lbs
Effects	Reverb, Chorus, Delay, Distortion, Rotary Speaker
Display	LCD
User Tones	100
Inputs/Outputs	USB
User memory	100 user tones
Controllers	Pitch Bend Wheel, Modulation Wheel
Inputs	Line In
Outputs	1/4" L/Mono, R output
Keyboard	61 keys
Connections	USB
