3. Motor xing
Fix each motor with the 6 screws M6x14 provided.
5. Articulated arm xing ( outward opening )
• Fix the 2 articulated arms to the motor shafts with the screws M6x12 provided;
• Offer the door plate to the door;
• Fix the plate with the 2 screws provided.
6. Mechanical check
• Move the side switches in position 0 and check the uency of the motion both in opening and in closing.
4. Door guides xing ( inward opening )
• Fix the 2 arms on the motor shafts with the screws M6x12 provided;
• Insert the guide on the sliding blocks;
• Set the external switch to position 0 and move the door to nd the best position for the door guide;
• Fix the guides on the doors with the 4 screws provided ;
Left Motor
Right Motor
6 x M6x14 screws for xing to the back-plate
