6
3) To exit the SPECIAL FUNCTIONS “Fx” menu, push and re-
lease the SPECIAL FUNCTIONS “Fx” (T3) key once.
T3
WARNING: The functions that can be selected depend on the
welding process activated. For this reason details of each func-
tion are given on the next pages, along with a description of the
welding processes.
SETUP Menu
Hold the PRG key down for at least 3 seconds to open the SET-
UP menu, which provides access to various functions, which are
suitable for expert operators. For further information, see table 1.
FACTORY DEFAULT (FAC)
WARNING: If carried out, this operation results in complete
resetting of all editable parameters to the factory settings (in-
cluding cancellation of the JOBS).
Table 1
FUNCTION DISPLAY
SETTINGS RANGE WELDING PROCESS MIG-MAG WELDING MODE
FACTORY RANGE
MIG MAG / PULSE
TIG MMA 2T 4T
Cra
2T
Cra
4T
Spot
2T
Stitch
2T
MiG
PLS
dPL MAn
ADJUSTABLE FUNCTIONS “Fx” Fx > 3s
MIG-MAG process
PRE GAS PrG 0.1s (0.0 ÷ 2.0)s ● ● ● ● ● ● ● ● ●
STARTING SPEED Sts 0 -30 ÷ +30 ● ● ● ● ● ● ● ● ●
HOT START Hot 0 -30 ÷ +30 ● ● ● ● ● ● ● ● ●
CRATER
INITIAL CRATER
CRATER START CURRENT F08 20% (-50 ÷ +100)% ● ● ● ●
CRATER START SPEED F08 5.0m/min (1.5 ÷ 22.0)m/min ● ● ●
CRATER START VOLTAGE F09 15.0V (10.0 ÷ 26.0)V ● ● ●
CRATER START TIME F10 1.0s (0.0 ÷ 20.0)s ● ● ● ●
CRATER START SLOPE F11 1.0s (0.0 ÷ 20.0)s ● ● ● ● ●
FINAL CRATER
CRATER END SLOPE F12 1.0s (0.0 ÷ 20.0)s ● ● ● ● ●
CRATER END CURRENT F13 -30 (-99 ÷ +50)% ● ● ● ●
CRATER END SPEED F13 5.0m/min (0.6 ÷ 22.0)m/min ● ● ●
CRATER END VOLTAGE F14 15.0V (10.0 ÷ 26.0)V ● ● ●
CRATER END TIME F15 0.0s (0.0 ÷ 20.0)s ● ● ● ●
SPOT WELD TIME F07 3.0s (0.1 ÷ 20.0)s ● ● ● ●
STITCH WELD
STITCH WELD TIME F05 1.0s (0.1 ÷ 20.0)s ● ● ● ●
STITCH WELD PAUSE F06 1.0s (0.1 ÷ 20.0)s ● ● ● ●
BURN BACK bUb 0 -30 ÷ +30 ● ● ● ● ● ● ● ● ●
POST GAS PoG 1.0s (0.0 ÷ 10.0)s ● ● ● ● ● ● ● ● ●
DUAL PULSE FUNCTIONS
DUAL PULSE DELTA CURRENT F23 40% (-50 ÷ +50)% ● ● ● ● ● ● ●
DUAL PULSE BALANCE F25 0% (-20 ÷ +20)% ● ● ● ● ● ● ●
DUAL PULSE FREQUENCY F26 1.5Hz (0.1 ÷ 2.5)Hz ● ● ● ● ● ● ●
TIG process
UP SLOPE F29 0.0s (0.0 ÷ 20.0)s ●
DOWN SLOPE F30 2.0s (0.0 ÷ 20.0)s ●
SWS VOLTAGE LIMIT F31 0 -30 ÷ 30 ●
MMA process
HOT START Hot 50 0 ÷ 100 ●
ARC FORCE ArC 50 0 ÷ 100 ●
PROGRAM DEFAULT dEF no no - YES ● ● ● ● ● ● ● ● ● ● ●
SETUP (SEtUP) menu PRG > 3s
FACTORY DEFAULT FAC no no - YES ● ● ● ● ● ● ● ● ● ● ●
SPECIAL FUNCTIONS (SPC FnC) menu PRG > 3s
SAFETY CALIBRATION CODE SCC 7 0 ÷ 100 ● ● ● ● ● ● ● ● ●
MOTOR CALIBRATION Mot CAL
SPEED MOTOR 1 SM1 75.0 50.0 ÷ 99.9 ● ● ● ● ● ● ● ● ●
SPEED MOTOR 2 SM2 75.0 50.0 ÷ 99.9 ● ● ● ● ● ● ● ● ●
SPEED MOTOR 3 SM3 75.0 50.0 ÷ 99.9 ● ● ● ● ● ● ● ● ●
