Cectec KINGCOBRA - Tail Lamp Assembly Dismantle

CHASSIS
Ⅲ
TAIL LAMP ASSEMBLY DISMANTLE
Pull out the wire,
then remove the seat wire
Dismantle the bottom bolt
from two sides of bracket
Dismantle the connector,
then remove the tail lamp
The tail lamp assy.
Ⅲ-47
