LHR & RHR LOWER ARM DISMANTLE
Dismantle the nuts and bolts
of arm, then remove the arm
Use the open wrench to lock
the ball joint, then dismantle
the nut
The lower arm
Ⅳ
-2
2
SUSPENSION / TRANSMISSION
※
Torque 70Nm
