LHR & RHR ABSORBER & UPPER ARM DISMANTLE
Dismantle the nuts and bolts
of absorber, then remove the
absorber
The absorber
Dismantle the nut and bolt
of arm, then remove the arm
The upper arm
Ⅳ
-2
1
SUSPENSION / TRANSMISSION
※
Torque 70Nm
※
Torque 70Nm
Ⅳ
169
171
