CHASSIS
Ⅲ
FRONT COVER DISMANTLE
Release the tenon from the
brake oil reservoir
Pull out the brake oil reservoir
Dismantle the bolt
Dismantle the screws from
two sides of the cover
Ⅲ-7
※Torque = 10 Nm
