Cectec KINGCOBRA - Gnd; Pin; Rollover (Fuel-Cut) Sensor; Ⅰ

Part Introduction
Sensor Voltage：12V
Sensor Pitch Angle：65°±10°
Sensor Roll Angle：-20°~+20°
Sensor Temperature：-10~+60℃
Circuit Diagram：
Assembly
Bolt：M4 Bolt x 2
Tighten Torque：1.5~2.5Nm
Measurement Resistance：3.9Ω ( Vcc + Output )
Vcc
GND
Output
Top ViewLeft View
Rollover (Fuel-Cut) Sensor
Ⅰ
Rollover
Sensor
ECU
Pin11
Vcc：12V
GND
OUTPUT
+
-
Ⅰ-16
