REAR STABILIZER BAR DISMANTLE
Dismantle the bolts of bar from
two sides
The stabilizer bar
Dismantle the nut of ball joint
Ⅳ -23
SUSPENSION / TRANSMISSION
The ball joint
※Torque 30Nm
※Torque 70Nm
Ⅳ
