ENGINE - Dismantle
Ⅱ
Ⅱ-2
CVT BELT DISMANTLE
Tighten the Belt Removal Tool
to end to open the driven pulley
then removal the belt
The belt
※Reinstall , the installer must
can read the printed word on
the belt
CVT DRIVEN PULLEY DISMANTLE
Loosen the driven pulley bolt ,
then remove the driven pulley
The Driven pulley
To Next Page
