Cectec KINGCOBRA - Start System

Starter Output：0.7KW
Operation Voltage：12V
Temperature Range：-10 ~ +120 ℃
Starter Circuit Diagram：
Start System
Ⅰ
Rewind Starter Handler
Starter
Spin Nose
Ring Gear
Starter
GND
Battery
GND
GND
Key S/W
Relay
Starter S/W
-
+
