Cectec KINGCOBRA - Pin; The Water Pump Assembly

12.1mm
Ⅱ
Ⅱ-36
THE WATER PUMP ASSEMBLY
N0. PART NAME PART NO.
1. ACCESSORY COVER 40010053
2. MECHANICLA SEAL
40136011
3.
SHAFT 40130075
4.
PROPELLER 40130071
5. WASHER 40130077
6. PI
N
40130083
7. GEAR (35T
)
40130063
8. CAP
40070064
9. RETAIN C-RING RCS012
Please clean up correlative parts and keep dry
1.After install mechanical seal (2) on water pump shaft (3) and
check the shaft have 12.1mm between mechanical seal and
water pump shaft
ENGINE - Assembly
