LHF & RHF HUB DISMANTLE
The flange of washer is lower,
when install the washer must in
the right direction
The flange of washer is lower,
when install the washer must in
the right direction
Pull out the hub
The hub
Ⅳ -4
SUSPENSION / TRANSMISSION
HUB SIDE
NUT SIDE
HUB SIDE
NUT SIDE
Ⅳ
