REAR GEAR BOX DISMANTLE
Dismantle the upper bolt of
gear box
Dismantle the lower nuts and
bolts of gear box
Lift the gear box
Ⅳ -27
SUSPENSION / TRANSMISSION
Turn the contraclockwise side
※Torque 25Nm
※Torque 40Nm
Ⅳ
