Ⅱ
Ⅱ-42
NGGC
BNG
B
CRANKCASE
BBN
A
321
CYLINDER BLOCK
N：No color G：Green B：Black
Choose bearing color and install to crankcase
EX：cylinder block mark is 1 A 1
crankcase mark is A 2 B
so we choose ALT side bearing color is No color (1&A)
1 A 1
A 2 B
and CVT side bearing color is Green (1&B)
1 A 1
A 2 B
※up and low bearing install the same color
CVT side
ALT side
The cylinder block mark
position , have 3 number
EX
：1 A 1
ENGINE - Assembly
