Ⅱ
Ⅱ-46
Lay the Case Assembly Glue
on cylinder block according
figure A and glue diameter
about 1mm
Install crankcase to cylinder
block
Keep away the main gallery
Figure A
Glue Path
Main Gallery
Lay the glue diameter about 1mm
ENGINE - Assembly
