Ⅱ
Ⅱ-52
Tighten the cylinder bolts
※Torque 35Nm + 90°
+ 90°
(tighten the four bolts equally)
※The M6 bolts torque 10Nm
Lubricate cam shaft
Install the cam shaft into
cylinder head
Lubricate the rock arms and
shafts , then install into
cylinder head
ENGINE - Assembly
To Next Page
