Ⅱ
Ⅱ-58
Install oil sump , then tighten
the bolts
※Torque 10Nm
Install the CVT drive pulley ,
then tighten the bolt
※Torque 120Nm
Install the driven pulley ,
then tighten the bolt
※Torque 45Nm
Tighten the Belt Removal Tool
to end to open the driven
pulley , then install the belt
ENGINE - Assembly
To Next Page
