FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
USE OF THE DEVICE
136 ORIGINAL INSTRUCTIONS
TEST FAILED for Sample too big
THS/21E THS/21
The signal given by the sample is
considered too high to perform a valid
test, according to SAC settings (see
Programming Manual).
=====================
TEST FE FAILED
SAMPLE TOO BIG
---------------------
[
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
]
TEST FE FAILED
SAMPLE TOO BIG
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(2)@
NFE test-1.00
SS test -1.20
2- SAMPLE TOO BIG
FE
~
T
es
t
~-
0
.
80
~~
NO(2)
@
NFE Test-1.00
SS test -1.20
2- SAMPLE TOO BIG
TEST FAILED for Ejection not confirmed
THS/21E THS/21
If the sample is correctly detected, but
there is not any confirmation of its
ejection, the test is considered to be
unsuccessful.
=====================
TEST FE FAILED
EJECT.NOT CONFIRM
---------------------
[
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
]
TEST FE FAILED
EJECT.NOT CONFIRM
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(3)@
NFE test-1.00
SS test -1.20
3- EJECT.NOT CONFIRM
FE
~
T
es
t
~-
0
.
80
~~
NO(3)
@
NFE Test-1.00
SS test -1.20
3- EJECT.NOT CONFIRM
TEST FAILED for Ejection timeout
THS/21E THS/21
If the ejection cycle is not completed
following an alarm within a minute of
starting the test, the test is considered
to be unsuccessful.
=====================
TEST FE FAILED
EJECTION TIMEOUT
---------------------
[
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
]
TEST FE FAILED
EJECTION TIMEOUT
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(3)@
NFE test-1.00
SS test -1.20
3- EJECTION TIMEOUT
FE
~
T
es
t
~-
0
.
80
~~
NO(3)
@
NFE Test-1.00
SS test -1.20
3- EJECTION TIMEOUT
TEST FAILED for synchronization photocell error
THS/21E THS/21
In the FS ejection mode, if the
synchronization photocell is not
activated following an alarm during the
test, the test is considered to be
unsuccessful.
=====================
TEST FE FAILED
SYNC PHOTOC.ERROR
---------------------
[
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
]
TEST FE FAILED
SYNC PHOTOC.ERROR
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(3)@
NFE test-1.00
SS test -1.20
3- SYNC PHOTOC.ERROR
FE
~
T
es
t
~-
0
.
80
~~
NO(3)
@
NFE Test-1.00
SS test -1.20
3- SYNC PHOTOC.ERROR
