Cessna 206H - Powerplant Instrument Markings

SOLOY TURBINE PAC SECTION 2
POHS CESSNA T206H/206H LIMITATIONS
2-7
F.A.A. Approved November 17, 2015
POWERPLANT INSTRUMENT MARKINGS
POWERPLANT INSTRUMENT MARKINGS
INSTRUMENT
LIMIT
BARBER
POLE*
RED LINE
GREEN
ARC
YELLOW
ARC
RED LINE
RED DOT
RED
DIAMOND*
START
LIMIT
MINIMUM
OPERATING
NORMAL
RANGE
CAUTION
RANGE
MAXIMUM
MAXIMUM
PEAK
START
LIMIT
PROPELLER
------
1630
to
1810
RPM
1480
to
1630
RPM
(4)(5)
1810
RPM
1990
RPM
(3)
N
1
12%-
15%
59%
59%-
105%
(1)
------
105%
106%
TORQUE
------
0-78
PSI
(2)
78-
101.4
PSI
101.4
PSI
TOT
150
------
400 -
738C
738 -
810C
810C
843C
(3)
927C
ENGINE OIL
(TEMP)
------
0-
107C
------
107C
------
ENGINE OIL
(PRESSURE)
50 PSI
90-130
PSI
(1)
50-90
PSI
(1)
130 PSI
------
150 PSI
TRANS-
MISSION OIL
(PRESS.)
40 PSI
40-60
PSI
------
60 PSI
------
Figure 2-4. Engine Instrument Markings.
