SOLOY TURBINE PAC SECTION 2
POHS CESSNA T206H/206H LIMITATIONS
2-8
F.A.A. Approved November 17, 2015
MISCELLANEOUS INSTRUMENT MARKINGS
Figure 2-5. Miscellaneous Instrument Markings.
NOTES: (1) N
1
and oil pressure limits are noted by a step in their respective
arcs.
N
1
Engine Oil Pressure
79% and below 50 – 130 psi
79% to 94% 90 – 130 psi
94% and above 115 – 130 psi
(2)* Minimum in flight torque is 14 psi.
(3) Not for intentional use.
(4) Limit - 60 seconds at torque settings greater than 20 psi.
(5) Aircraft incorporating an “enhanced” power turbine wheel per
Rolls-Royce CEB A-1365 must include the yellow arc extending
from 1358 rpm to 1630 rpm.
* These markings are depicted on the optional two inch engine
instruments.
WEIGHT LIMITS
Ramp Weight: 3617 lbs.
Maximum Takeoff Weight: 3600 lbs.
Maximum Landing Weight: 3600 lbs.
Maximum Weight in Baggage Compartment – Station 109 to 145:
180 lbs. (See note below).
NOTE
Refer to Section 6 of this handbook for loading
arrangement with one or more seats for cargo
accommodation.
