7
SITE PREPARATION
Check the national and local building codes BEFORE installation.
INTRODUCTION
Gate must be constructed and installed according to ASTM F2200
standards (refer to page 4). Gate must fit specifications of operator
(refer to specifications).
GATE
Install catch rollers with safety
covers on the side of a post or
wall with a minimal distance of
half an inch between the rollers
and gate.
DO NOT use a gate catch post.
Because the coasting distance
may vary due to changes in
temperature, it is NOT
recommended to install a stop
or catch post in front of the
gate's path. To do so will cause
the gate to hit the post in certain
instances.
SAFETY CATCH ROLLERS
Conduit must be UL approved for low and high voltage. Consider
the operator placement BEFORE installing the pad or post.
Concrete Pads
CONDUIT & CONCRETE PAD
Entrapment protection devices are required to protect against any
entrapment or safety conditions encountered in your gate
application. Install warning signs on both sides of the gate.
Warning Signs
SAFETY
VEHICLE LOOPS
(Inside Property)
The vehicle loops allow the gate to stay open when vehicles are
obstructing the gate path. Suggested for vehicles 14 feet (4.27 m)
or longer. Vehicle loops are not required but are recommended.
