6
OPERATOR SPECIFICATIONS
This model is intended for use in vehicular slide gate applications:
INTRODUCTION
15.1" (38.4 cm)
Usage Classification Class I, II, III, & IV
Main AC Supply
Model SL3000501U 1/2 HP: 120 Vac, 6 Amps (12 Amps including accessory outlets)
Model SL3000101U 1 HP: 120 Vac, 12 Amps (18 Amps including accessory outlets)
Accessory Power 24 Vac, 500 mA max. for ON + SW (switched)
Maximum Gate Weight Model SL3000501U 1/2 HP: 1000 lbs. (453.6 kg)
Model SL3000101U 1 HP: 2000 lbs. (907.2 kg)
Minimum Gate Travel Distance 4 feet (1.2 m)
Maximum Gate Travel Distance 52 feet (15.85 m)
Maximum Gate Travel Speed 1 foot/second
Maximum Daily Cycle Rate Continuous
Maximum Duty Cycle Continuous
Operating Temperature Without Heater: -20°C to 60°C (-4°F to 140°F)
With Optional Heater: -40°C to 60°C (-40°F to 140°F)
Expansion Board Provided
Inherent Entrapment Protection (Type A) RPM
External Entrapment Protection (Type B1 and/or
Type B2)
3 inputs per board - any combination of up to 3 photoelectric sensors and up to 2 edge sensors
18.3" (46.5 cm)
24" (61 cm)
18.1" (46 cm)
21.6" (54.9 cm)
21.5" (52.1 cm)
26.5"
(67.3 cm)
