Chamberlain Elite SL3000 User Manual

8
INTRODUCTION
OVERVIEW OF TYPICAL INSTALLATION
IMPORTANT SAFETY INFORMATION: One or more external monitored entrapment protection sensors shall be located where the risk of entrapment or
obstruction exists at either the opening or closing direction. Any gap larger than 2-1/4 inches between the gate and a fixed object such as a wall, pillar,
column, or operator must be filled.
SINGLE GATE
DUAL GATE
Operator
Water Tight Conduit
(Not provided)
NOTE: Power and control wiring
MUST be run in separate conduits.
Earth Ground Rod
Check national and local
codes for proper depth
Warning Sign
Photoelectric
Sensors
Safety Catch
Roller
Operator
Water Tight Conduit
(Not provided)
NOTE: Power and
control wiring MUST be
run in separate
conduits.
Earth Ground Rod
Check national and local
codes for proper depth
Warning Sign
Photoelectric
Sensors
Safety Catch Roller
Edge Sensor
Edge Sensor
Edge Sensor
Edge Sensor
