CHART Orca MicroBulk CO2 Series - Receiving Tank Commission: Hose Reel; Receiving Tank Commission: Bulk Hose

19
OperationsProduct Manual - Orca
™
CO
2
Series MicroBulk Delivery System
20. Close receiving tank ll valve and re-open Dispense
(V-41) valve to allow liquid in hose to warm and travel
back into Orca CO
2
.
21. Close Vapor Balance (V-41) and receiving tank vapor
balance valves. Open and close Vapor Balance Line
Drain (V-45) valve to depressurize.
22. On Chart printer-equipped models.
a. Open printer box, press RELEASE to insert paper into
printer, press FORWARD to lock paper in.
b. On Flowcom, press EXIT, PRINT. When printing is
complete, press printer RELEASE, remove paper and
close door.
23. On Flowcom press CLEAR, CLEAR, and DELIVERY
to return to deliver screen.
Note: ThispreparestheFlowcomforthenext
delivery.
24. Power o Flowcom. This also powers o the printer.
25. Close Dispense (V-41) valve. Open line drain at
receiving tank and shake hose to get all liquid out.
26. Once de-pressurized, open Dispense Line Drain (V-8) to
ensure hose is empty and de-pressurized.
Caution! Use best practices to properly
drain the liquid and keep from
forming pressurized dry ice
plugs.
27. Disconnect CGA size adapter, bulk delivery hose and
stow.
a. Reconnect Hose Reel Delivery Flex Hose (DC-3),
open Dispense (V-41) & Delivery Flex Hose (V-47)
valves.
b. Optional: purge and pressurize per “VI Pressure
Delivery 6. a.”
28. Close cabinet doors and stow hoses. Replace all dust
caps.
29. Disengage engine speed control and disengage PTO.
30. Keep pressure build heater running or turn o as
necessary.
Note: This procedure can also be used for
pump transferring through the Hose Reel
FlexHoseinsteadofthebulkhose.
Note: UseCGAtting1.0”-1.5”sizeadapters
as necessary.
Note:TofullyemptyOrcaCO
2
, dump the truck
airbagsorparksothebackoftheOrca
CO
2
islowerthanthefront.
VIII. Receiving Tank Commission:
Hose Reel
— Follow steps 1-4 in “VI. Pressure Delivery” for
pre-delivery instructions.
1. Connect Hose Reel Inlet (DC-3) to Vapor Balance (DC-
5).
2. Open Vapor Balance (V-44) and Delivery Flex Hose
(V-47) valves.
3. Connect Hose Reel Dispense (DC-4) to receiving tank
ll.
4. Open Delivery Hose (V-46) valve and pressurize tank to
100 psig.
5. Close Delivery Hose (V-46), Vapor Balance (V-44) and
Delivery Flex Hose (V-47) valves.
6. Open Vapor Balance Line Drain (V-45) valve and close
when depressurized. Replace dust cap on Vapor Balance
(DC-5).
7. Disconnect Hose Reel Inlet (DC-3).
8. Refer to “VI. Pressure Delivery” for further
instructions.
IX. Tank Commission: Bulk Hose
— Follow Steps 1-4 in “VII. Pump Delivery” for
pre-delivery instructions.
1. Connect Bulk Transfer Hose to Vapor Balance (DC-5)
and receiving tank ll connection.
2. Open Vapor Balance (V-44) and receiving tank ll
valves. Pressurize receiving tank to 100 psig.
3. Close Vapor Balance (V-44) and receiving tank ll
valves.
4. Open Vapor Balance Line Drain (V-45) and close when
depressurized.
