Components & SystemsProduct Manual - Orca
™
CO
2
Series MicroBulk Delivery System
Plumbing Cabinet - Curb Side
Item Tag Description
A V-7 Valve, Bypass
B P-1 Pump
C RV-11 Relief Valve, Pump Discharge
D RTD-1 Resistance Temperature Device
E MTR-1 Motor
F CPL-1 Coupler, Motor to Pump
G Motor High Pressure Side
H Motor Low Pressure Side
I Motor Case Drain
A
B
C
D
E
F
G
H
I
