Error Cause Task
E032 Meter System serial numbers have not
been entered yet.
Checksum error identified when reading
the corresponding settings.
Configure device. See also section 6 “Parameters/Settings.”
The calibration seal does not need to be broken.
E033 General settings of the meter system
have not bee entered yet.
Checksum error identified when reading
the corresponding settings.
Configure device. See also section 6 “Parameters/Settings.”
The calibration seal does not need to be broken.
E034 The License Key for the selected
application has not been entered yet.
Enter License Key.
E035 Expansion module not connected or
defective.
Check connection cable (ribbon cable) and/or replace.
Expansion module.
E040 Battery Voltage lower than 1.82V
(Nominal value is 3.0V).
Replace battery. Check date and time of internal clock and set if
necessary.
E041 - E047 Main supply voltage too low. Address fault in main voltage supply.
Replacement of mother board (needs recalibration).
E048 Environmental temperature too low. Address fault in main voltage supply.
Replacement of mother board (needs recalibration).
Overview of Warnings
Warning Code Cause Task
W040 Battery voltage lower than 2.5V
(Nominal value is 3.0V).
Replace battery.
Confirm warning (device can be operated further).
Check date and time of internal clock and set if necessary.
W041 - W047 Main supply voltage too low. Confirm warning.
W048 Environmental temperature too low. Confirm warning.
Circuit boards A,
B or C do not pass
on power up.
Circuit board is bad or lost program. Replace board or reload program.
