CHART Orca MicroBulk CO2 Series - Technical Specifications; Specs, Diagrams, and Nomenclature

47
Product Manual - Orca
™
CO
2
Series MicroBulk Delivery System
Specications
Model 3.8 Ton 5.5 Ton 6.5 Ton 10.5 Ton 13 Ton
Type Truck Trailer
Real Axle Single Tandem
Over 33,000# FET No Yes
Design Code DOT MC-338
Flow Meter Type Flowcom® Flow Meter System
Pressure Build Type ThermaFired
TM
or ThermaFired XL
TM
Specications 3.8 Ton 5.5 Ton 6.5 Ton 10.5 Ton 13 Ton
Gross Capacity
(gal/L)
903 / 3,418 1,293 / 4,895 1,556 / 5,890 2,463 / 9,323 3,116 / 11,795
MC-338 Capacity
(gal/L)
857 / 3,244 1,225 / 4,637 1,480 / 5,602 2,340 / 8,858 2,961 / 11,209
MAWP psig/bar 350 / 24.1
Overall Length (in/
cm)
146 / 371 181 / 460 205 / 521 253 / 643 346 / 879
Overall Height (in/
cm)
68 / 173
Overall Width (in/
cm)
85 / 216
Tank Diameter (in/
cm)
66 / 168
Tare Weight (lbs/kg) 6,900 / 3,136 8,600 / 3,909 9,700 / 4,409 13,700 / 6,227 16,700 / 7,575
Performance 3.8 Ton 5.5 Ton 6.5 Ton 10.5 Ton 13 Ton
Pressure Transfer Standard
100’ Hose on Reel Standard
Pump Transfer Standard
Min Dispense Rate*
(lb/min, kg/min)
50 / 22.7
Max Dispense Rate*
(lb/min, kg/min)
500 / 227
Max Dispense Pres-
sure (psig/barg)
Pressure: 350 / 24.1
Pump: 400 / 27.6
* Min and Max Dispense Rates are based on NTEP approval and dependant on many variables: Orca pressure, re-
ceiver pressure, liquid temperature, ow circuit restriction, etc.
**Tare weights are estimated, and calculations will be conrmed when each size is built.
Full Trycock Weight of Lading by Model based on Saturation Pressure
Saturation
Pressure
(PSI)
Density
(#/gal)
Temp.
(°C/°F)
3.8 Ton 5.5 Ton 6.5 Ton 10.5 Ton 13 Ton
lbs. kg. lbs. kg. lbs. kg. lbs. kg. lbs. kg.
350 8.28 -13.23/8.2 7,096 3,225 10,143 4,610 12,254 5,570 19,375 8,806 24,517 11,144
300 8.49 -18.41/-1.13 7,276 3,307 10,400 4,727 12,565 5,711 19,867 9,030 25,139 11,426
250 8.70 -24.24/-11.63 7,456 3,389 10,658 4,844 12,876 5,852 20,358 9,253 25,761 11,709
200 8.94 -31.04/-23.87 7,662 3,482 10,952 4,978 13,231 6,014 20,920 9,509 26,471 12,032
150 9.20 -39.23/-38.61 7,884 3,583 11,270 5,122 13,616 6,189 21,528 9,785 27,241 12,382
100 9.52 -49.75/-57.55 8,159 3,708 11,662 5,300 14,090 6,404 22,277 10,125 28,189 12,813
70 9.75 -64.95/-84.91 8,356 3,798 11,944 5,429 14,430 6,559 22,815 10,370 28,870 13,122
