Check Point 4600 - Expansion Line Cards

Front Panel Components
Check Point 4000 Appliances Hardware Page 33
When Entering an IP Address
To
Press
Enter the grub menu
Move to the next digit
Move back to the previous digit
Approve the change
when the cursor is located on the last digit
Cancel the IP change
when the cursor is located on the first digit
Change current digit
or
Expansion Line Cards
Check Point 4000 Appliances contain one optional expansion slot that accommodates cold-
swappable network line cards. There are different types of expansion line cards which contain
two, four, or eight ports. These types of expansion line cards are currently available:
Model
Description
CPAP-ACC-2-10F
2 Port 10GBase-F SFP+ (without transceivers)
CPAP-ACC-4-1C
4 Port 10/100/1000Base-T RJ-45
CPAP-ACC-4-1C-BP
4 Port 10/100/1000Base-T RJ-45 bypass
CPAP-ACC-4-1F
4 Port 1000Base-F SFP (without transceivers)
CPAP-ACC-4-1F-BP
4 Port 1000Base-F SFP bypass (without transceivers)
CPAP-ACC-8-1C
8 Port 10/100/1000Base-T RJ-45
