CHINT NVF5 Series User Manual

NVF5 Series User Manual Chapter 6 Parameter Function Description
Set AI Voltage / Current
input sacale
F5.33 ～ F5.36 Curve 3Setting
F5.37 ～ F5.44 Curve 4Setting
（Step4）AI curve setting
modes：
AI curve selection and filter
time setting
F5.21 ～ F5.22 AI1、AI2 Filter Setting
 AI Curve Modes：
There are 4 kinds of AI curve modes,curve 1、curve 2、curve 3 are 2 points style curve，
refer to parameters F5.25 ～ F5.36.Curve 4 is 4 points style curve 为 4，refer to
parameters F5.37 ～ F5.44。
Code
Name
Default
Setting Range
Description
F5.25
Curve 1 Min. Reference
0.00V 0.00V ～ F5.27
100.0% is
the Scale
percentage
of F0.07-
Max. Output
Frequency
F5.26
Curve 1 Min. Reference
Setting
0.0% （-100.0 ～ +100.0）%
F5.27
Curve 1 Max. Reference
10.00V F5.25 ～ +11.00V
F5.28
Curve 1 Max. Reference
Setting
100.0% （-100.0～ +100.0）%
F5.29
Curve 2 Min. Reference
0.00V 0.00V ～ F5.31
F5.30
Curve 2 Min. Reference
Setting
0.0% （-100.0～ +100.0）%
F5.31
Curve 2 Max. Reference
10.00V F5.29 ～ +11.00V
F5.32
Curve 2 Max. Reference
Setting
100.0% （-100.0～ +100.0）%
F5.33
Curve 3 Min. Reference
0.00V 0.00V ～ F5.35
F5.34
Curve 3 Min. Reference
Setting
0.0% （-100.0～ +100.0）%
F5.35
Curve 3 Max. Reference
10.00V F5.33 ～ +11.00V
F5.36
Curve 3 Max. Reference
Setting
100.0% （-100.0～ +100.0）%
The setting of the AI curve is actually to set the scale relationship between the analog
input voltage (or the analog input current ) and the corresponding frequency setting .
When AI signal is as frequency reference，100% of the voltage or current analog input
corresponds to the percentage of relative (Max. Output Frequency F0.07). For 2 points
style curve setting and parameters description, please see below figure，（Curve 2、curve
- 44 -
