NVF5 Series User Manual Chapter 6 Parameter Function Description
F6.02
Relay Output
Selection
16
0 ～ 63
F6.03
Reserve
--
--
F6.04
Output Terminal
Effective Status
Setting（HDO、RO）
0x0000
0x0000 ～ 0x0003
F6.05
HDO Output Delay
Time
0.0s
（0.0 ～ 3600.0）s
F6.06
HDO Output Setting
Selection
0.0s
（0.0 ～ 3600.0）s
DO Terminal Function Description：
Values
Function
Description
0 No Applicable
The terminals that are not used can be set to
"No Applicable" to prevent misoperation.
1
In Running Mode
Inverter is in Running mode, DO is effective.
2
Frequency Level
Detection Reach-FDT1
Refer to F6.14、F6.15 description
3
Frequency Level
Detection Reach -FDT2
Refer to F6.16、F6.17 description
4
Inverter Overload
Pre-Alarm
Inverter is in Overlaod status, DO is effective.
5
Under Voltage Status
Output
DC Bus voltage is lower than Under Voltage
Limit, DO is effective.LED indicates P.oFF。
6 External Fault Stop
Inverter External Fault occurs and trip
fault“E.EF”时，DO is effective.
7
Reach Upper Limit
Frequency
Setting Frequency≥Upper Limit Frequency,and
the
running frequency reach the Upper Limit
Frequency，DO is effective.
8
Reach Lower Limit
Frequency
Setting Frequency≤Lower Limit Frequency,and
the running frequency reach the Lower Limit
Frequency
，DO is effective.
9 Zero Speed Running
Inverter runs and the output frequency is 0, DO
is effective.Inverter is in Stop Mode,DO is
ineffective.
10 ~ 11
Reserve
--
12
Simple PLC Step
Complete Indication
Simple PLC Step Complete, DO is effective.
13 PLC Recycle Complete
Simple PLC recycle completer，DO is effective.
15 Inverter Ready
If the output signal is effective, it means that the
inverter is fault-
free, the DC Bus Voltage is
normal, the Disable Terminal of is ineffective,
and inverter can startst.
16
Fault Output
Inverter Fault, DO is effective.
17 ~ 18
Reserve
--
- 82 -
