NVF5 Series User Manual Chapter 6 Parameter Function Description
35
Reverse Disable
Disable reverse running
36 Accel./Decel. Disable
Maintain current output frequency（Except Stop
command）
37 UP/DN Reset to 0
When the main frequency is set by the integral
keypad, the DI terminal selection function can
clear the frequency value changed by the
Up/Down keys, and let the frequency reference
restore to parameter F0.05 setting.
38
Reserve
--
39 PLC Pause
PLC function pause, and inverter maintains
current Output Frequency
40 PLC Disable
PLC disable,if the frequency source is Simple
PLC reference,the system will switch to parameter
FA.46 setting
41
PLC Stop Memory
Clear
PLC Stop and Memory clear
42
PLC Reset
Recover inverter to Simple PLC initial status
43 PID Integration Pause
PID Integration function pause, but the
proportional adjustment and differential regulation
are still effective.
44 PID Disable
PID is disable,if frequency source is close loop
PID reference，switch to parameter F9.29 setting
45 PID Invert
PID function is opposite to Parameter F9.15
setting
46 PID Parameter Switch
When PID Switch Selection( F9.20) set to 1
（Switch by DI），When DI is ineffective，using PID
parameters F9.03 ～ F9.05 ；
When DI is
effective,using PID parameters F9.17 ～ F9.19。
47
Reserve
--
48
DC Brake
Inverter switch to DC brake mode directly.
49
Frequency Setting
Effective Terminal
If DI terminal is On, allow modification
frequency.If DI terminal is Off, prohibit
modification frequency.
50
Reserve
--
51
Current RunningTime
Clear
Inverter current running time is cleared to 0
6.11.2 Digital Output Terminal Function（DO）
NVF5 series has 1 standard Digital Output terminal,1 multifunctional Relay Output
terminal, terminal configuration is as below.
Code Name Default Setting Range Description
F6.00 HDO Output Type 0
0 ～ 1
See Below
Table
F6.01 HDO Output Selection 1
0 ～ 63
- 81 -
