CHINT NVF5 Series User Manual

NVF5 Series User Manual Chapter 6 Parameter Function Description
parameters、
PID parameters)are restored,DI is
off,inverter recovers to the memory state before.
10 Ramp Stop
Stop command is effective to all running mode，
When it is ON,the Stop Mode is set according to
parameterF1.05
11
DC Brake
Deceleration
Program DI terminal to realize DC Injection
Brake,and realize motor emergency stop and
precise positioning.DC brake frequency、 DC
brake waiting time,DC brake current are set in
parameters F1.06～F1.09
12 Coast Stop
Set to coast stop，same as parameter F1.05
13
Terminal Accel. UP
When frequency source is sent to Digital Given,DI
terminal can be used on Accel. And Decel.
frequency ，
Regulation Rate is set by
parameterF0.12 UP/DN
14
Terminal Decel.
DOWN
15
Switch to Keypad
Command
For selecting different Digital Input
Command.Program command chennel switch
between Integral keypad、Terminal、Comm.
16
Swith to Digital Input
Command
17
Switch to
Comm.Command
18
Main Frequency
Resouce Swich to
Digital Given
When effective, the main frequency reference is
switched to Digital Given 、 AI1 、 AI2 or HDI
reference.
19
Main Frequency
Resouce Swich to AI1
20
Main Frequency
Resouce Swich to AI2
21
Reserve
22
Main Frequency
Resouce
Swich to
HDI
24
Preset Speed
Terminal 1
Program 4 DI to preset speed, and realize max.
15 preset speed.
25
Preset Speed
Terminal 2
26
Preset Speed
Terminal 3
27
Preset Speed
Terminal 4
28
Accel./Decel Time
Selection Terminal 1
Program DI to 4
kinds of Accel./Decel. Time
selection.
29
Accel./Decel Time
Selection Terminal 2
34
Forward Disable
Disable forward running
- 80 -
