Chore-Time C2 PLUS User Manual

MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System Wiring
MF2495A
33
Mechanical Switch Three Phase(Ø) Wiring Diagram: 220 V.
Mechanical Switch Three Phase(Ø) Wiring Diagram: 380/415 V.
95
END CONTROL
96
K1
PHASE
PHASE
PHASE
L2 L3
T2 T3
C1
CONTACTOR
K1
1255-109 10/2000
L1
T1
FROM DISCONNECT OR
CONTROL DISCONNECT
220 VOLTS 50 HZ
THREE PHASE
TO ADDITIONAL
FEEDER LINES
SET OF FUSES
SHORT CIRCUIT
PROTECTION
(NOT SUPPLIED)
CURRENT SENSOR
(AVAILABLE)
FEEDER LINE MOTOR
220/230 VOLTS 50 HZ
THREE PHASE
MID LINE
CONTROL UNIT
CONTROL BYPASS SWITCH
(NOT SUPPLIED)
M1
3 PH
C1
END CONTROL
96
1255-110 10/2000
95
K1
PHASE
PHASE
PHASE
NEUTRAL
L2 L3
T2 T3
C1
L1
CONTACTOR
CURRENT SENSOR
(AVAILABLE)
K1
T1
FROM DISCONNECT OR
CONTROL DISCONNECT
380/415 VOLTS 50 HZ
THREE PHASE
TO ADDITIONAL
FEEDER LINES
SET OF FUSES
SHORT CIRCUIT
PROTECTION
(NOT SUPPLIED)
MID LINE
CONTROL UNIT
FEEDER LINE MOTOR
380/415 VOLTS 50 HZ
THREE PHASE
CONTROL BYPASS SWITCH
(NOT SUPPLIED)
M1
3 PH
C1
