MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System Parts List
MF2495A
55
*These items are included in the Parts Package.
**Actuator Switch, Chore-Time part number 7114, is no longer available. When replacing, use 7114 Switch
Replacement Kit Part Number 46678.
Item Description MODEL
C2 PLUS
Standard
Part No.
40943
MODEL
C2 PLUS
Shallow
Part No.
42012
MODEL
G PLUS
Standard
Part No.
40944
MODEL
G PLUS
Shallow
Part No.
42028
1 Control Body 14434 14434 14434 14434
2 Deflector Panel 41363 41363 41363 41363
3 Paddle Retainer 25045 25045 25045 25045
4 Control Cover Assembly 24682 24682 24682 24682
5 Danger Decal 2527-9 2527-9 2527-9 2527-9
6 1/4-20x1-1/2 Socket Hd Screw 5083-8 5083-8 5083-8 5083-8
7 Driver Block 4642 4642 4642 4642
8 Drive Tube Weldment 44794 44794 44794 44794
9 Bottom Cover 14432 14432 14432 14432
10 Control Cord Assembly 25495 25495 25495 25495
11 1/2” Liquid Tight Connector 24685 24685 24685 24685
12 Switch Box 24702 24702 24702 24702
13* Switch Bracket 46122 46122 46122 46122
14* Switch Insulation 1907-5 1907-5 1907-5 1907-5
15** Actuator Switch 46091 46091 46091 46091
16 1/2” Liquid Tight Connector 23810 23810 23810 23810
17 14” Flexible Conduit 26982-1 26982-1 26982-1 26982-1
18 Straight Liquid Tight Connector 26980 26980 26980 26980
19 Cut Sleeve 43110 43110 43110 43110
20 Anchor Plate 4188 4188 4188 4188
21 Center Support Assembly 40947 37371 40947 37371
22 Feeder Grill 39567 39567 38599 38599
23 Mylar Assembly 25318 25318 25318 25318
24 Feeder Pan 41501 41500 41501 41500
25 Adjustment Cone 38604 41504 38604 41504
26 Switch Box Cover 6776 6776 6776 6776
27 Switch Box Gasket 6777 6777 6777 6777
28 Danger/Product Identification Decal 2529-660 2529-697 2529-659 2529-698
29 Support Bracket 24683 24683 24683 24683
30 Spring 6972 6972 6972 6972
31 #10-32 Lock Nut 6963 6963 6963 6963
32 Paddle 46123 46123 46123 46123
33 Gasket 6968-1 6968-1 6968-1 6968-1
34 Actuator Pin 8757 8757 8757 8757
35 Switch Box Mount 25084 25084 25084 25084
36 Stop Panel 25433 25433 25433 25433
37 Switch Bracket 40749 40749 40749 40749
-- Anti-Roost Guard 2798 2798 2798 2798
-- Parts Package 40809 40809 40809 40809
